Powering ESP32 breakout board without using USB port

Postby Albert » Tue Nov 21, 2017 4:50 pm

Hi Guys,

I have a Node MCU breakout board for the ESP32 chip. I'm wondering if there's a way i can power the board using the breakout pins and not the USB port. I have a 5V pin and 3.3V pin. I'm wondering whether i could use any of these to power the board?

ESP_Sprite
Posts: 1218
Joined: Thu Nov 26, 2015 4:08 am

Re: Powering ESP32 breakout board without using USB port

Postby ESP_Sprite » Wed Nov 22, 2017 10:13 am

Looks like your shift key got stuck while typing the title; I've undone that for you.

kurtzweber
Posts: 48
Joined: Tue Jan 10, 2017 1:09 pm

Re: Powering ESP32 breakout board without using USB port

Postby kurtzweber » Wed Nov 22, 2017 4:48 pm

Albert wrote:Hi Guys,

I have a Node MCU breakout board for the ESP32 chip. I'm wondering if there's a way i can power the board using the breakout pins and not the USB port. I have a 5V pin and 3.3V pin. I'm wondering whether i could use any of these to power the board?


I think you should check the schematics of your board... for example: does it contain a voltage regulator? How the 5v pin is connected to the rest of the components? Is it sourced from the USB port?

Albert
Posts: 10
Joined: Wed Oct 11, 2017 3:06 pm

Re: Powering ESP32 breakout board without using USB port

Postby Albert » Wed Nov 22, 2017 8:14 pm

Thanks. I've really looked for the schematic but i just cannot find it.

User avatar
Gfast2
Posts: 107
Joined: Fri Aug 11, 2017 1:52 am

Re: Powering ESP32 breakout board without using USB port

Postby Gfast2 » Thu Nov 23, 2017 2:58 am

Hi Albert,

I have two NodeMCU ESP32. ;) This is the best I can get:Image Link

My test equipment is right now not available for me, so perhaps you wanna probe PIN19 on J1 first. Just figure out if it is shorted to 5V from USB first.

Cheers

Gfast2

Albert
Posts: 10
Joined: Wed Oct 11, 2017 3:06 pm

Re: Powering ESP32 breakout board without using USB port

Postby Albert » Thu Nov 23, 2017 9:11 am

Hey Gfast2,

Thank you for the schematic. From the schematic, Pin 19 seems to have a diode in between it and the 5V from USB. So I gathered courage and decided to supply 5V on the 5V pin and the RED led came on . The strange thing is that the access point i have created using the chip is no longer visible on the list of wifi networks. But when I power it via USB, it becomes visible . I wonder why?

Albert

User avatar
Gfast2
Posts: 107
Joined: Fri Aug 11, 2017 1:52 am

Re: Powering ESP32 breakout board without using USB port

Postby Gfast2 » Thu Nov 23, 2017 9:36 am

Hey Albert,

nice to hear you have some results :D

Yeh, I was a "Arduino Boy", I did really a lot things around Arduino some years before. (www.gao-su.com). From my very limited experience around this topic. I believe a very practical way to debug this is grab a usb cable you do not wanna have, cut it in the middle and rewire up its wires except the 5V (normally the red one) from you computer.In this way, you can at least check out through serial monitor if the ESP32 fired up or not.

Before you do that, you can try to solder a kable on the big foot of the SMD part that markt with "AMS1117" (a LDO, -> Datasheet). If you have a solder iron on your bench.


Cheers

Gfast2

Albert
Posts: 10
Joined: Wed Oct 11, 2017 3:06 pm

Re: Powering ESP32 breakout board without using USB port

Postby Albert » Thu Nov 23, 2017 3:28 pm

Gfast2,

I have found out something very interesting. The access point was disappearing because whenever power is disconnected and then reconnected again, the 'EN' button on the board has to be pressed for the access point to appear on the list of WiFi networks. So it had nothing to do with powering the USB.

I also realized that whenever i connect my Digital Multi Meter to the 3.3V pin on the board,the access point disappears from the list of networks.

It seems that i have another problem with my circuit which i will post under another topic.


Thank you so much for the help!

User avatar
urbanze
Posts: 73
Joined: Sat Jun 10, 2017 9:55 pm
Location: Brazil

Re: Powering ESP32 breakout board without using USB port

Postby urbanze » Thu Nov 23, 2017 3:32 pm

Gfast2 wrote:Hi Albert,

I have two NodeMCU ESP32. ;) This is the best I can get:Image Link

My test equipment is right now not available for me, so perhaps you wanna probe PIN19 on J1 first. Just figure out if it is shorted to 5V from USB first.

Cheers

Gfast2


Hello @Gfast2! You said that this scheme is the most similar to your plates. Can you test me something? My badge does not fit this schematic.

It's very simple, feed the NodeMCU-32 through the Vin pin and see if the ON LED (normally red) lights up.

Now, feed through the 3.3v pin and see if the ON LED lights up, which according to schematic, the LED is on the 5v track making it not turn on, but here it turns on :(

It would also be interesting if you measured the current consumption of these two feeds if you can.

User avatar
Gfast2
Posts: 107
Joined: Fri Aug 11, 2017 1:52 am

Re: Powering ESP32 breakout board without using USB port

Postby Gfast2 » Fri Nov 24, 2017 3:52 pm

urbanze wrote:
Gfast2 wrote:Hi Albert,

I have two NodeMCU ESP32. ;) This is the best I can get:Image Link

My test equipment is right now not available for me, so perhaps you wanna probe PIN19 on J1 first. Just figure out if it is shorted to 5V from USB first.

Cheers

Gfast2


Hello @Gfast2! You said that this scheme is the most similar to your plates. Can you test me something? My badge does not fit this schematic.

It's very simple, feed the NodeMCU-32 through the Vin pin and see if the ON LED (normally red) lights up.

Now, feed through the 3.3v pin and see if the ON LED lights up, which according to schematic, the LED is on the 5v track making it not turn on, but here it turns on :(

It would also be interesting if you measured the current consumption of these two feeds if you can.


Hi urbanze,

Because some new job, I just didn't get the chance to test my board as you said. But I've check out my board visually. There is not such a "VIN" exist.

Cheers

Gfast2
